24" Solar Powered Flashing Crosswalk Sign

Code: CCRS002

$799.99

FOR STANDARD SIGNS ONLY:
FOR BACK TO BACK SIGNS ONLY:
CHOOSE COLOR OPTION:

Qty

Product Description

•••••

This is a LED solar traffic safety warning sign built based off MUTCD requirements. It is built for commercial, residential, school and government. This pedestrian crossing sign will increase visibility for drivers on the road or in shopping centers with its bright blinking (flashing) LED lights.



Product Specifications:

·       MUTCD: W11-2 Pedestrian Crossing Sign

·       PRODUCT CODE: CCRS002

·       TYPE:Solar LED Traffic Safety Sign

·       SOLAR CHARGING PANEL:12V, 5w Monocrystalline silicone

·       LED COLOR RANGE:Yellow/ Amber

·       WORKING MODE:All Day or Just Evening, flashing

·       BATTERY:Lithium battery 7.4V/4400AH

·       VISIBLE DISTANCE:>2500 feet

·       WORKING TIME:After one full charge, 5-7 consecutive days

·       BATTERY LIFE SPAN:3-5 Years

·       WARRANTY: 3 Year Full Warranty

·       SIGN COLOR:Engineer grade yellow

 Option: Fluorescent Yellow/ Green (only in diamond grade)

·       DIMENSIONS:24-inch Diamond (24"x24")

 Packing dimensions: 26" x 26" x 3", 1 Piece

Solar LED Traffic Safety Sign can be used on streets, in parking lots and more. Since these are solar powered, they can be used anywhere there is sun light. This product is very simple to install and use.



JUNCTION BOX (BATTERY HOUSING)

  ·     STANDARD:5W /12V Solar Panel, 7.4V / 4400mAH Battery

       ·     UPGRADED: 8W / 12V Solar Panel, 7.4V / 6600mAH Battery (Longer Battery Life

        ·     NOTE: BACK TO BACK SIGNS AUTOMATICALLY COME WITH UPGRADED BATTERY

             & SOLAR PANEL



DOUBLE SIDED (Back to Back) Configuration Includes:

·      QTY: 2 - 24" Crosswalk Signs

·      QTY 1 18v/8w Solar panel

·      QTY 1 11.1v/8.8ah battery

·      QTY 1 Battery Box



The CCRS002 adheres to the MUTCD standards found within MUTCD guidelines Section 2A.07 for Retro-reflectivity and Illumination


·       Illumination of a sign by Light emitting diodes (LEDs)

·       Sign Element to be Illuminated: (1) Symbol or word message (2) Portions of the sign border

·       LED's are placed within 1 border unit of border and within words

·       LED's are yellow/amber in color

·       LED's are within 1/4" in width

·       LED's flashing at a rate of 50 times per minute

·       Background of sign is standard 3M reflective engineering grade material



DOWNLOAD PRODUCT SHEET
