InstAlert 18 with Portable Post and Battery Power
    InstAlert 18 with Portable Post and Battery Power
    Purchase InstAlert 18 with Portable Post and Battery Power
    • SKU: ATS-INSA-18-BAT-PTP
      InstAlert 18 with Portable Post and Battery Power

    • $4,997.00

      Shipping Weight: 45.00 pounds

      Quantity in Basket:  None

    • Message Suite:
      SHIPPING RATE:
    •

    For shipping outside of the United States, please call us at 888-925-1966 or email us at sales@ledlighting-solutions.com to receive a quote.


    Introducing the ATS-INSA-18-BAT-HTM, a dynamic addition to portable traffic messaging—the InstAlert 18 with Hitch Mount and Battery Power. This versatile system, with hitch specifications for easy integration, unfolds to an 18” x 28” full matrix display. The InstAlert offers a range of operational modes, allowing you to display one message, sequence through all messages, or schedule changes up to 13 times a day. The ATS-INSA-18-BAT-HTM sets a new standard for portable traffic messaging. Welcome to a versatile, reliable solution for on-the-go communication.



    PRODUCT SPECIFICATIONS:



           TYPE: InstAlertt 18 with Portable Post and Battery Power

           PRODUCT CODE: ATS-INSA-18-BAT-PTP

    FOLDING PORTABLE POST SPECIFICATIONS:

           Folds for easy storage and portability

           42" to 55" to bottom, 70" to 83" to top of sign depending on leg positions, rotate bracket for additional 12"

           POWERcase portable power supply


    SIGN SPECIFICATIONS:

    · InstAlert 18: 18” x 28” full matrix

    · Size and weight without battery - 30” x 20” x 2.74, 29 lbs.

    · Full matrix display

    · Universal mounting system: Attach to pole, trailer, or vehicle hitch mount

    · Meets MUTCD specifications



    Instalert Operation Modes

    · Message Mode: Display one message, up to six screens

    · All Messages: Sequence all messages in sign memory

    · Schedule: Change message and/or mode up to 13 times per day

    · Sign returns to last configuration when power applied



    InstAlert Programming Methods

    · Onboard programming (standard on all units):

    · Select operation mode

    · Select message from sign memory



    InstAlert Messages

    · IA18: 1–2-line messages

    o  1 line: 10 1/4” H x 5.75” W characters, four per line

    o  2 lines: 7” Hx4” W characters, six per line

    ·     Up to six screens per message

    ·     Full graphics capability, each LED individually controllable

    ·     Variable display time, flash, and reverse rates for each screen

    ·     Scroll through 25 user defined onboard messages using selector buttons built into sign, no training necessary

    ·     Ability to sequence messages for up to 144 screen animation

    ·     Message power efficiency calculator in software

    ·     Actual sign preview and unlimited message storage using TraffiCloud Web-based Remote Management Service, ATS PC Sign Manager or ATS Android app

    ·     Messages on sign retained when power removed

    ·     Sign returns to last message when power applied

    ·     Conditional Messaging – Dynamically display messages driven off sensors and/or incorporate into messages



    InstAlert Programming

    ·     Configure the following parameters via TraffiCloud Web-based Management System, ATS Android app or PC Sign Manager

    ·     Messages Create and load message u sing ‘Display Now’ feature Load 24 messages into sign’ s memory

    ·     Scroll messages in sign’s memory Display signs stored in TraffiCloud Web, ATS Android app or PC Sign Manager



    Scheduling

    ·     All Days, Multiple Messages: Schedule up to 50 different messages or modes for up to 13 different time periods in a 24-hour day, repeats in each 24-hour cycle

    ·     Seven Day, Multiple Messages: Schedule different messages or modes for up to 13 different time periods in each 24-hour day for each of seven days, repeats in each seven-day cycle; up to 50 different messages can be used over the seven-day period

    ·     All messages and scheduling reside on the sign – no external hardware necessary

    ·     Program schedule via TraffiCloud Web, ATS Android app or ATS PC Sign Manager, save to load onto multiple signs

    ·     Internal real–time clock, time and schedule maintained with power disconnected



    Construction

    ·     LED Pixels: Amber 595nm, 30-degree viewing angle,100,000 hours, black background, (MUTCD • compliant)

    ·     LED Density: 0.6”x1” pitch,18x48pixelmatrix

    ·     Conformal coating on all circuit boards

    ·     Integral handle

    ·     Weatherproof, NEMA 4, IP65 sealed

    ·     1⁄4” Tinted, non-glare, UV stabilized polycarbonate face

    ·     Drip proof, vented battery compartments (2)

    ·     Aluminum chassis, 14 ga, white powder coat finish, black powder coat front for maximum contrast for display visibility

    ·     Tamper resistant mounting hardware system, hardware, controls, and battery access secured behind enclosure lock

    ·     –40 to 160 F operating temperature range, 95% humidity non-condensing (–20F for Bluetooth communication, 5F for internal camera)



    InstAlert Power

    ·     Power Input, Max:12 VDC, 3 A max, 36 W max

    ·     Power saving circuitry and automatic dimming for ambient light conditions with adjustable dimming range and manual display brightness override

    ·     InstAlert 18 Power Options:

    o  16AhLFPbatterywithbuilt-in short circuit and reverse polarity protection circuitry; 1.5A 12.8 VDC output, 120VAC input automatic charger; Capacity for up to 2 batteries in unit for extended portable use

    ·     Solar panel assist: 40W or 60W solar panel and bracket, Solar controller panel with 26Ah lead acid battery; 6A 120VAC automatic charger optional 100-220VAC AC power supply (6A 12VDC) in external NEMA 4 enclosures



    Warranty: ATS 3-year Manufacturer’s Warranty comes standard on all InstAlert variable message signs
